    10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase

    Ask Lasest Price
    Brand Name : Foton
    Model Number : BJ5163
    Certification : ISO/FCC/SGS
    Price : negotiation
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 30 per month
    Delivery Time : 30-40 working days after receipt balance payments
    • Product Details
    • Company Profile

    10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase

    10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro3 Cummins Engine 5150 Wheelbase


    Description:


    With sufficient power and good quality, it is your good transportation partner. Optional air deflector, height 3910 with air deflector, height 3570 without air deflector, optional color registration and word mark. Correspondence between curb weight/maximum allowable weight of semi-trailer saddle/total weight of quasi-trailer: 8850/16020/40000,9730/15140/39140. 10 Ton Cargo Truck Chassis


    Service we can provide:
    10 Ton Cargo Truck Chassis,yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.Foton Tractor Truck
    Except the products, we can also provide sepcial USED VEHICLES AND USED MACHIENRY export business. We warmly welcome all customers and friends who need our service, and happy to build long-term relationship with you.Foton Tractor Truck

    Overall dimensions9000x2496x2760mmCurb weight7760kg
    Van dimensions5200x2200x500mmLoading capacity10T
    Chassis modelBJ5163Chassis brandFOTON
    Overall dimensions8455X2405X2700mmWheel base5150mm
    Front/rear wheel track1960/1847mmFront/rear suspension1365/2440 mm
    Approach/departure angle16/11°Maximum speed79km/h
    Chassis ManufacturerBeijing Foton Daimler Motor Co., Ltd.
    CabConfigurationETX2200 cab(with sleeping berth),allowable 3+2 passengers, ETX interior, air conditioner, machinery seat
    ColorWhite, other color is optional
    EngineModelB210 33
    EmissionEuro 3
    Type6 cylinders, in-line,diesel engine
    Rated power210hp, rated power speed 2500rpm
    Displacement5900ml
    Max.torque700N.m
    Bore x stroke102x120mm
    ManufacturerBeijing Foton Cummins Engine Co. Ltd.
    TireSize11R22.5
    Number6+1 nos
    Fuel tank260L aluminum fuel tank
    Front axel4.2T
    Rear axle10T
    Drive form4X2
    SuspensionMulti leaf springs
    Rated voltage24V, DC
    TransmissionsGear box 8JS85T, 8 speed forward 1 reverse.
    Steering devicePower assisted steering
    Steering wheelLeft hand drive
    Selective configuration
    If there is a slight change in the chassis parameters above, please take the actual product as the standard
